Coal dryer

Semi coke dryer

Rotary Dryer Machine is widely used in industrial materials, metallurgy, chemical industry and cement industry, which is widely used to dry the stuff such as limestone, coal powder, slag and clay.

  • Type: Drum Drying Equipment, rotary drum dryer
  • Application: Chemicals Processing, mining, building materials
  • Application for materials: Building materials , biomass ,fuels industry,semi coke,coal ,mining,etc
  • Heating source: Coal, wood, oil, natural gas
  • Capacity: 2-100t/h
  • Place of Origin: China
Leave message Inquiry

Rotary Dryer Machine is widely used in industrial materials, metallurgy, chemical industry and cement industry, which is widely used to dry the stuff such as limestone, coal powder, slag and clay.

It can be widely used in:

1. The coal industry: Coal slime, coal, flotation clean coal, mixed clean coal etc.

2. The construction industry: Blast furnace slag, clay, bentonite soil, lime stone, sand, quartz stone etc.

3. Ore processing industry: Various metal concentrates, slag, tailings etc.

 4. Chemical industry: Non-drying heat sensitive materials

Industrial Rotary Dryers are widely used in:

1. The coal industry: Coal slime, coal, flotation clean coal, mixed clean coal etc.

2. The construction industry: Blast furnace slag, clay, bentonite soil, lime stone, sand, quartz stone etc.

3. Ore processing industry: Various metal concentrates, slag, tailings etc.

 4. Chemical industry: Non-drying heat sensitive materials

Coal slime rotary dryer is a kind of stable and reliable heating drying equipment, designed to dry materials of high moisture and strong stickiness, such as coal slurry, mud, gypsum, humid swell soil, electroplate mud and so on. The performance of coal slime dryer is better than tube rotary dryer and blade rotary dryer.

 Coal slime rotary dryer special features:

  • · Drying material with co-current or counter-current hot gas, the heating efficiency can be up to 95%.
  • · Coal Slime dryer should be operated under high temperature and low oxygen to avoid materials being burnt when drying.
  • · Large drying capacity, highly industrialization and low cost.

Lignite rotary dryer main applicable areas:

  • 1. Coal industry: drying coal, coal slime, coal with flotation, drying mixed coal;
  • 2, Construction industry: drying cinder, blast furnace slag, clay, limestone, sand, quartz;
  • 3, Mining processing industry: drying metal concentrates, slag, tailings;
  • 4, Chemical industry: heat non-sensitive materials.



Model (mm) Inclination (%) Rotate speed (r/min) Air inlet temperature (°C) Drum

power (kw)

 Processing capacity (t/h) Weight (t)
Φ600×6000 2-3 6-9 ≤700 3 0.3-0.5 2.3
Φ800×8000 2-3 6-9 ≤700 4.4 0.5-0.8 3.5
Φ1000×10000 2-3 6-9 ≤700 6 1.0-1.5 5.6
Φ1200×12000 2-3 6-9 ≤700 7.5 3.0-5 11.4
Φ1500×14000 2-3 6-9 ≤700 15 7-9 16.8
Φ1800×16000 2-3 6-9 ≤700 22 12-15 26
Φ2000×18000 2-3 6-9 ≤700 37 15-18 30.5
Φ2200×18000 2-3 6-9 ≤700 45 20-25 35.7
Φ2400×18000 2-3 6-9 ≤700 55 25-30 49.2
Φ2600×20000 2-3 6-9 ≤700 75 35-42 64
Φ2700×20000 2-3 6-9 ≤700 90 45-50 80.2
Φ3000×20000 2-3 6-9 ≤700 110 50-60

105.3
