Grain Dryer

Fruit/vegetable /food Drying Oven

It is widely used for drying  pharmaceutical, chemical, foodstuff, light and heavy industries.especially for the fruit and vegetable   food processing.such as leaf vegetables,   cabbage, onions,carrot, apples, lemons ,orange,  pulms,bananas,pineapples,jujube,etc.

  • Fan (Kw): 0.45+0.12
  • Heat System (Kw): 9
  • Capacity (Kg): 60
  • Heating Area (㎡）: 7
  • Air Volume (㎡/h): 3000
  • Tray Material: S.S
  • Dimension （mm）: 1480*1200*2200
Leave message Inquiry

The HG Series Hot Air Circulation Drying Oven is a box-like shape which can be easily disassembled and fixed; it includes CT series (centrifugal blower) and CT-C series (axial flow blower). The heat source the drying oven can be steam and electricity.

This product is equipped with high temperature proof axial flow blower and automatic temperature control system. The entire circulating system is fully sealed and it increased the thermal efficiency (traditional ovens 3%-7%, current oven 35%-45%), the highest thermal efficiency can reached 70%.

Application:

The drying oven is suitable for drying and dehydration of material and product for pharmaceutical, chemical, food, agricultural, aquatic, light industry, heavy industry; such as medicine raw material, medicine, Chinese herbal medicine, extractum, granules, powder, pill, packing bottle, pigment and dyes, dehydrated vegetables, dried fruit, sausages, plastic, resin, electric elements, varnish, and etc.

1.The hot air is circulated in the oven, high thermal efficiency and energy saving.

2.It utilizes the forced ventilating function with adjustable air distribution plates inside of the oven to makethe raw material can be dried uniformly.

3. Temperature be controlled automatically. Installation and maintenance are simple and easy.

4. Widelyused for different

Model Heat System Capacity Heating Area Air Temparature(℃） Tray Tray Dimension
Data Fan (Kw) (Kg) (㎡） Volume （pcs） Material （mm）
(Kw) (㎡/h)
HG-I 0.45+0.12 9 60 7 3000 0-120 24 S.S 1480*1200*2200
HG-II 0.45+0.12 18 120 14 3400 0-120 48 S.S 2400*1200*2200
